General AUXG07KVLA User Manual

Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
31
-10.0 8.6 2.31 9.7 2.36 10.3 2.37 11.0 2.40 11.8 2.43 12.1 2.44
0.0 8.6 2.08 9.7 2.12 10.3 2.13 11.0 2.16 11.8 2.18 12.1 2.19
5.0 8.6 1.94 9.7 1.97 10.3 1.99 11.0 2.01 11.8 2.04 12.1 2.05
10.0 8.6 1.88 9.7 1.91 10.3 1.93 11.0 1.95 11.8 1.97 12.1 1.98
15.0 8.6 1.98 9.7 2.01 10.3 2.03 11.0 2.05 11.8 2.08 12.1 2.09
20.0 8.6 1.97 9.7 2.00 10.3 2.02 11.0 2.04 11.8 2.07 12.1 2.08
25.0 8.6 2.23 9.7 2.27 10.3 2.29 11.0 2.31 11.8 2.34 12.1 2.35
30.0 8.6 2.68 9.7 2.72 10.3 2.75 11.0 2.78 11.8 2.81 12.1 2.82
35.0 8.6 3.23 9.7 3.29 10.3 3.31 11.0 3.35 11.8 3.39 12.1 3.41
40.0 6.4 2.40 7.2 2.45 7.6 2.47 8.2 2.49 8.7 2.52 9.0 2.54
46.0 6.4 1.58 7.2 1.61 7.6 1.62 8.2 1.64 8.7 1.66 9.0 1.67
30
-10.0 8.4 2.24 9.5 2.28 10.0 2.30 10.7 2.32 11.4 2.35 11.8 2.36
0.0 8.4 2.01 9.5 2.05 10.0 2.06 10.7 2.09 11.4 2.11 11.8 2.12
5.0 8.4 1.88 9.5 1.91 10.0 1.93 10.7 1.95 11.4 1.97 11.8 1.98
10.0 8.4 1.82 9.5 1.85 10.0 1.86 10.7 1.89 11.4 1.91 11.8 1.92
15.0 8.4 1.91 9.5 1.95 10.0 1.96 10.7 1.99 11.4 2.01 11.8 2.02
20.0 8.4 1.90 9.5 1.94 10.0 1.95 10.7 1.98 11.4 2.00 11.8 2.01
25.0 8.4 2.15 9.5 2.19 10.0 2.21 10.7 2.23 11.4 2.26 11.8 2.27
30.0 8.4 2.59 9.5 2.63 10.0 2.66 10.7 2.69 11.4 2.72 11.8 2.73
35.0 8.4 3.12 9.5 3.18 10.0 3.20 10.7 3.24 11.4 3.28 11.8 3.30
40.0 6.2 2.33 7.0 2.37 7.4 2.39 7.9 2.41 8.5 2.44 8.8 2.45
46.0 6.2 1.53 7.0 1.56 7.4 1.57 7.9 1.59 8.5 1.60 8.8 1.61
28
-10.0 7.8 2.06 8.9 2.10 9.3 2.11 10.0 2.14 10.7 2.16 11.0 2.17
0.0 7.8 1.85 8.9 1.88 9.3 1.90 10.0 1.92 10.7 1.94 11.0 1.95
5.0 7.8 1.73 8.9 1.76 9.3 1.77 10.0 1.79 10.7 1.81 11.0 1.82
10.0 7.8 1.67 8.9 1.70 9.3 1.72 10.0 1.74 10.7 1.76 11.0 1.77
15.0 7.8 1.76 8.9 1.79 9.3 1.81 10.0 1.83 10.7 1.85 11.0 1.86
20.0 7.8 1.75 8.9 1.78 9.3 1.80 10.0 1.82 10.7 1.84 11.0 1.85
25.0 7.8 1.98 8.9 2.02 9.3 2.04 10.0 2.06 10.7 2.08 11.0 2.09
30.0 7.8 2.38 8.9 2.43 9.3 2.45 10.0 2.47 10.7 2.50 11.0 2.52
35.0 7.8 2.88 8.9 2.93 9.3 2.95 10.0 2.98 10.7 3.02 11.0 3.03
40.0 5.8 2.14 6.6 2.18 6.9 2.20 7.4 2.22 7.9 2.25 8.2 2.26
46.0 5.8 1.41 6.6 1.43 6.9 1.44 7.4 1.46 7.9 1.48 8.2 1.49
27
-10.0 7.5 1.96 8.5 1.99 9.0 2.01 9.6 2.03 10.3 2.06 10.6 2.07
0.0 7.5 1.76 8.5 1.79 9.0 1.81 9.6 1.83 10.3 1.85 10.6 1.86
5.0 7.5 1.64 8.5 1.67 9.0 1.69 9.6 1.70 10.3 1.72 10.6 1.73
10.0 7.5 1.59 8.5 1.62 9.0 1.63 9.6 1.65 10.3 1.67 10.6 1.68
15.0 7.5 1.68 8.5 1.71 9.0 1.72 9.6 1.74 10.3 1.76 10.6 1.77
20.0 7.5 1.67 8.5 1.70 9.0 1.71 9.6 1.73 10.3 1.75 10.6 1.76
25.0 7.5 1.89 8.5 1.92 9.0 1.94 9.6 1.96 10.3 1.98 10.6 1.99
30.0 7.5 2.27 8.5 2.31 9.0 2.33 9.6 2.35 10.3 2.38 10.6 2.39
35.0 7.5 2.73 8.5 2.78 9.0 2.81 9.6 2.84 10.3 2.87 10.6 2.89
40.0 5.6 2.04 6.3 2.07 6.7 2.09 7.1 2.11 7.6 2.14 7.9 2.15
46.0 5.6 1.34 6.3 1.36 6.7 1.37 7.1 1.39 7.6 1.40 7.9 1.41
NOTES:
• TC: Total Capacity (kW), IP: Input Power (kW)
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• 2 or more indoor units should be connected.
• The total ability of connected indoor unit is from 27,000 Btu/h up to 54,000 Btu/h.
• Input in the table are calculated based on the maximum indoor unit input combinations.
- 387 -
6-2. Cooling capacity
6. Capacity table
