General DCS312 User Manual

WHAT’S IN THE CASE
The DCS312 and its accessories come in a custom molded plastic case. The
instrument has two main components: a wand-type grip with an integral LCD
monitor, and a 12mm flexible-obedient camera-tipped probe. Also in the case are:
• A plastic bag containing three probe tip accessories: the 45° mirror,
pickup hook and magnetic pickup
• A video cable with a black mini-plug on one end and a yellow RCA plug
on the other
• This user’s manual
PRODUCT OVERVIEW
Fig. 1 shows the main components and accessories of the DCS312. Fig. 2 shows
the positions of its display, controls and connectors. Familiarize yourself with their
names and functions before moving on to the Setup Instructions.
Fig. 1. The main components and accessories of the DCS312 system
1. Wand-type grip and integral 3.5 in. LCD
2. A/V cable
3. Pickup hook
4. 45° mirror
5. Magnetic pickup
4
1
3
4
5
2
