General GSE-110 - Weights and Dimensions; Receiving

GSE-109-110-112 SLICER
6
P/N GENSLICERMAN
RevA 10-2011
SPECIFICATIONS
(CONTINUED)
GSE-109
GSE-110
WEIGHTS AND DIMENSIONS
MODEL
GSE-109
DIM A DIM B DIM C WEIGHT
16.0 in 18.0 in 15.0 in 37.5 lbs
406 mm 457 mm 381 mm 17 Kgs
MODEL
GSE-110
DIM A DIM B DIM C WEIGHT
17.0 in 21.0 in 15.0 in 44.1 lbs
432 mm 533 mm 381 mm 20.0 Kgs
A
B
C
B
A
C
