The IRT659K can measure surface temperature using either of two methods:
non-contact (using an IR thermometer with a laser pointer) or contact (using a
“K” type thermocouple). A “K” type thermocouple with a wide measurement
range is included in the package. The instrument automatically stores its last
10 IR readings in a nonvolatile memory for later recall in reverse chronological
order. During a single scanning session, the IRT659K simultaneously displays
real-time measurements on a main readout and the maximum, minimum,
average or largest difference between measurements during that session on
a smaller readout.
The IRT659K and “K” type thermocouple, a “9V” battery and this user’s manual
are sold together with a nylon pouch in a blister pack.
KEY FEATURES & SPECIFICATIONS
• 12:1 distance-to-spot (D:S) ratio
• -58° to 1202°F (-50° to 650°C) IRT measurement range
• -146° to 2498°F (-99° to 1370°C) “K” type thermocouple measurement
range; included thermocouple has 0° to 500°F (-18° to 260°C) range
• Backlit 1.5 in. (38.1mm) diagonal LCD
• IRT measurement accuracy of ±3°F (2°C) or ±2% of reading
(whichever is greater) above 32°F (0°C)
• Automatically holds measurements
• Automatically stores last 10 readings for recall
• Displays Min/Max/Avg/Dif temperatures captured during each
scanning session
• Settable high and low temperature alarms
• °C/°F, laser pointer on/off and backlight on/off switches
• ½ second response time
• Emissivity is adjustable from 0.1 to 1.0 (in 0.01 steps),
with default value of 0.95
• 30 second Auto Power Off
