KEY FEATURES
• Includes separate moisture-resistance curves for wood
and building materials
• 99.9 count green backlit LCD w/0.3 in. high digits
• Low, medium and high moisture level lights
• Audible high moisture alert
• Reading HOLD button
• Replaceable stainless steel test pins
• Pin cap doubles as calibration checker
• Low battery indication
• 3-minute Auto Power Off
• Powered by “9V” battery (included)
• 1 year limited warranty
WHAT’S IN THE PACKAGE
The MMD4E comes in a blister pack with a factory-installed
“9V” battery. Two replacement 9mm (0.35 in.) long test pins—
General Part No. PIN3DE—are included.
PRODUCT OVERVIEW
Fig. 1 on the next page shows all of the controls, indicators,
and components on the front and top of the MMD4E, as well
as the location of the battery compartment on its back.
A. Protective pin cap with calibrating resistor inside
B. Test pins with black rubber sleeves (sleeves not shown)
C. LCD
3
