PRODUCT OVERVIEW
Fig. 1 shows the labels and positions of the VIC’s display, controls and physical structures.
Familiarize yourself with their functions before moving on to the setup and operating
instructions.
4
1. Press to generate a local WiFi network
2. Press to increase/decrease camera
lighting
3. Press to start/stop recording of video clip
(enabled only when linked to ToolSmart
app)
4. Press to take a still photo of the displayed
image (enabled only when linked to
ToolSmart
app)
5. Press to power the VIC on and off
6. Battery compartment
7. 1m long, 8mm diameter probe
8. Camera head
9. LCD
10. RESET button (on back); see page 7
11. Triangular hanger hook (behind monitor)
INCLUDED ACCESSORIES
12. 45° mirror
13. Pickup hook
14. Magnetic pickup
Fig. 1. The VIC’s controls,
physical structures
and accessories
10
9
11
12 3
6
7
8
4 5
FACEPLATE
12
13
14
