Fig 1. The TS05’s controls, indicators and physical features
5
A
E
I
F
G
H
B
C
D
A. Laser pointer
B. Infrared sensor/lens
C. Measurement trigger
D. Battery compartment
E. Backlit white-on-black (reverse-
type) LCD
F. button. Turns laser on and off.
G. button. Pressed briefly, sends
measurement data to smartphone
app via Bluetooth. Pressed and
held, activates/deactivates
Bluetooth transmission.
H. °C/°F button. Selects temperature
unit
I. Laser Identification/
Certification/Warning/Safety Labels
(on left side); see below
