the number of Data Matrix bar codes determined by information encoded in those
bar codes. Once the proper number of codes is reached, the data is output in the
order specified in the bar codes. Default = On.
Data Matrix Code Page
Data Matrix Code pages define the mapping of character codes to characters. If the
data received does not display with the proper characters, it may be because the
bar code being scanned was created using a code page that is different from the
one the host program is expecting. If this is the case, scan the bar code below,
select the code page with which the bar codes were created (see ISO 2022/ISO
646 Character Replacements), and scan the value and the Save bar code from the
Programming Chart on the inside the back cover of this manual. The data
characters should then appear properly.
Grid Matrix
<Default All Grid Matrix Settings>
Grid Matrix On/Off
* On
Off
Data Matrix Code Page
On
* Off
To Next Page
