Generation Lighting Kent 82029 - Install the Fixture; Ground Connection; Neutral Wire Connection; Hot Wire Connection

2
1A
Connect the fixture to a suitable ground in accordance to local electrical codes.
Connect the white fixture wire (square and/or rigid) to the neutral power line wire with a wire nut.
Connect the black fixture wire (round and/or smooth) to the hot power line wire with a wire nut.
Neatly tuck in any wiring, place the fixture base onto the post and secure with post screws.
Screw the lamp into the socket. Refer to the label on the socket for Max Wattage Information.
Install the top cover and secure it in place with the washers and cap nuts.
1
2
3
4
5
6
NEUTRAL WIREHOT WIRE
WHITE WIRE
BLACK WIRE
POST SCREW
FIXTURE BASE
LAMP
Install the Fixture
TOP COVER
POST
4
6
CAP NUT
4
5
6
WASHER
3 2
