110
SITEMONITOR 6
Klemmenbezeichnung:
Anschluss:
X1 / 15V +
Betriebsspannung
+15VDC
X1 / -
GND -
X2/D01
Digital Input 1
X2/D02
Digital Input 2
X2/D03
Digital Input 3
X2/D04
Digital Input 4
X2/D05
Digital Input 5
X2/D06
Digital Input 6
X2/D07
Digital Input 7
X2/D08
Digital Input 8
X2/D09
Digital Input 9
X2/D10
Digital Input 10
X2/D11
Digital Input 11
X2/D12
Digital Input 12
X2/D13
Digital Input 13
X2/D14
Digital Input 14
X2/D15
Digital Input 15
X2/D16
Digital Input 16
X2/D17→ D64
Digital Input 17→ 64
