38
Apply/Cancel
This function saves the entered data and restarts the corresponding services on the fly. A complete reboot of the CS411 is not
necessary:
- Apply: Save changes and restart the service as required
- Cancel: Withdraw settings and return to current state.
-
Note:
The standard UPS Modbus addresses can be found in the appendix of this manual starting on page XXX.
The CS141 uses a valid Modbus reading range from 0-65535. Some Programs like "Modbus Poll" use the same range. Other
Modbus polling clients may use 1 - 65536 - in this case, you need to correct this by adding 1 to the original value.
SNMP Agent
For this configuration step, navigate to the following menu:
Developed by the IETF the Simple Network Management Protocol is designed for monitoring and controlling network elements
from a central station. The protocol controls the communication traffic between monitored devices and monitoring stations:
SNMP describes the structure of the data packets that can be sent as well as the entire communication process. The CS141
can fully be integrated into a network with SNMP monitoring. The build-in SNMP agent regulates both -
receiving and sending corresponding requests
Note:
SNMP V1.0 is not officially supported by the CS141. We recommend the use version 2.0 upward. However, since V1.0 is largely
included in V2.0, the CS141 will respond to SNMP-V1 requests, but using V1.0 will be out of official supporter’s guidance.
The CS141 supports SNMP v2 as well as SNMP v3
The difference that SNMP v2 and v3:
SNMP v2 works on behalf of legitimating an IP address inside user communities, SNMP v3 is based on direct user permissions
with name and password.
