KNOWING YOUR HAMMER DRILL
UNPACKING AND CONTENTS
IMPORTANT: Due to modern mass production techniques, it is unlikely the tool is
faulty or that a part is missing. If you find anything wrong, do not operate the tool until
the parts have been replaced or the fault has been rectified. Failure to do so could result
in serious personal injury.
CONTENTS IN PACKAGE
Description Q'ty
Hammer Drill 1
Auxiliary Handle 1
Depth Gauge 1
Chuck Key 1
Operator's Manual 1
OPERATION
WARNING: Always check that the power supply corresponds to the voltage
on the rating name plate.
WARNING: Always be sure that the tool is switched off and unplugged
before adjusting, adding accessories, or checking a function on the tool.
SWITCH TRIGGER
Your tool is equipped with a variable speed switch trigger (1-FIG1). The tool speed is controlled by the amount of
pressure you apply to the switch trigger. By slowly increasing the pressure on the switch trigger, tool speed will
gradually increase until reaching maximum rated RPM.
1
5
9
2
6
7
3
4
8
1. Switch Trigger
2. Lock-ON Button
3. Forward/Reverse Lever
4. Speed Control Dial
5. Mode Selector
6. Chuck
7. Auxiliary Handle
8. Depth Gauge
9. Chuck Key
FIG 1
