GENI MOVING HEAD OBY-5 - Channel 8- Prism-wheel; Channel 9- Iris; Channel 10- Focus; Channel 11- Pan reguration

11
Channel 8- Prism-wheel
Open position
Triple prism static
Triple prism forwards rotation from fast to slow
Triple prism backwards rotation from slow to fast
Triple prism static
1
7
132
253
255
0
2
8
133
254
Channel 9- Iris
Closed
Min. Diameter to max. diameter
Iris-in from slow to fast
Iris-out from fast to slow
Open
159
207
253
255
0
1
160
208
Iris-in Iris-out
Channel 10- Focus
Focus adjustment from far to near
255
0
Channel 11- Pan reguration
CH-11
The “head” of the unit is allowed to turn horizontally from
zero to 570 degrees.
253
CH-11
The “head” of the unit is allowed to turn horizontally from
zero to 570 degrees.
254
254 -255
