Channel 16- Lamp switch
Standby
Lamp "on" 3 seconds later
Standby
Lamp "off" 3 seconds later
Standby
47
95
159
207
255
0
48
96
160
208
Channel 12 Tilt reguration
The “head” of the unit is allowed to turn vertically from
zero to 270 degrees
Channel 13 Pan fine-tune
While rotating horizontally the “head” is allowed to be
fine tuned from zero to 2.2 degrees.
Channel 14 Tilt fine-tune
While rotating vertically the “head” is allowed to be
fine tuned from zero to 1 degree.
12
Channel 15 - Control
CH 12
