Figure 12 Current Power Connector w/o tie wrap on position 4(D)
Thread a six-inch (6”) cable tie between the positive and negative wires of Tower D’s power cable.
(Figure 13)
Figure 13 Cable tie on power connector
Connect the power connector to the mating receptacle on the power distribution board and thread
the cable tie through the metal leads of the connector that is soldered to the power distribution
board. (Figure 14)
Figure 14 Properly tie wrapped power connector
