Zenith15/25 Pro | 14User Interface
Description of the LEDs
IF the is THEN
Bluetooth LED green Bluetooth is in data mode and ready for connecting.
blue Bluetooth has connected.
RTK Base LED green Zenith15/25 Pro is in RTK base mode. No RTK data is being
passed to the interface of the communication device.
flashing green Zenith15/25 Pro is in RTK base mode. Data is being passed
to the interface of the communication device.
RTK Rover LED green Zenith15/25 Pro is in rover mode. No RTK data is being
received at the interface of the communication device.
flashing green Zenith15/25 Pro is in rover mode. RTK data is being received
at the interface of the communication device.
Position LED off no satellites are tracked.
flashing yellow less than four satellites are tracked, a position is not yet
available.
yellow a navigated position is available.
flashing green a code-only position is available.
green a fixed RTK position is available.
Power LED off battery is not connected, flat or Zenith15/25 Pro is switched
off.
green power is 20% - 100%.
red power is 5% - 20%. The remaining time for which enough
power is available depends on the type of survey, the
temperature and the age of the battery.
fast flashing red power is low (<5%).
Storage LED off no microSD card is inserted.
green microSD card is inserted but no raw data is being logged.
flashing green raw data is being logged.
flashing red raw data is being logged but only 5% memory left.
red microSD card is full, no raw data is being logged or no
microSD card is inserted but Zenith15/25 Pro is configured
to log raw data.
