Geotech G100 Quick Start Guide

Geotech
Sovereign House, Queensway, Leamington Spa, Warwickshire, CV31 3JR
geotechuk.com sales@geotech.co.uk +44 (0)1926 338111
PAGE 2 OF 2 | OMG100QSG1
Note: A red backlight is displayed if the
pump is stalled or the alarm is acvated.
For further informaon, please refer to
Operang Manual secons on Alarms
and Flow Fail.
A Temperature 1 connector measures temperature
– incubator and ambient temperatures.
B Temperature 2 connector measures temperature
– incubator and ambient temperatures.
Temperature connectors are ed with black plugs to prevent
dust ingress, remove before use. Grip connector cap and pull
upwards to release. Ret when not in use.
C Humidity probe (oponal) aachment point.
D Gas outlet port used to exhaust the gas.
E Gas inlet point used to aach the sample tube
and lter in order to take the gas reading.
F USB cable aachment point. Used to connect the analyser
to a PC via a USB cable to download data.
G Mains baery charger point. Used to aach the mains
charger to the analyser for charging.
A Main read screen
B So-keys
C On/o key
D Pump key
E Key 4 - scroll le
F Key 8 - scroll down
G Menu key
H Enter key
I Key 2 - scroll up
J Key 6 - scroll right
K Moisture removal tube
L Serial number
M Kick stand
ICON DESCRIPTION
Baery charge state
(Flashing)
< 1 hour remaining
(Flashing)
Baery charging
Charged
Pump running
(Flashing)
Pump stalled (backlight turns red)
Alarm set
(Flashing)
Alarm acve (backlight turns red)
USB connected to PC
(ickers when transferring data)
Logging mode acve
(ashes when memory nearly full)
Temperature probe(s) connected
Humidity probe connected
(Flashing)
Service due (every 12 months)
Service overdue
Fault/repair
Waing
G100 QUICK START GUIDE www.geotechuk.com/G100
G10 0
C
D
E
F
G
I
J
H
K
L
M
A
B
A
F
G
B
C
D
E
To view the complete operating manual, please go to the
LITERATURE section at www.geotechuk.com/g100
