Specification:
Model: GEPRC RAD VTX 5.8G 1.6W
Inputvoltage: DC 7-36V(2-8S Battery)
Output: 5V@600mA(Power5Vtocamera)
Inputimpedance: 75Ω
Protocol: IRCTramp
Antennaconnector: MMCX connector
Cable connector: GH1.25-6P connector
Outputpower: 25mW/200mW/600mW/1600mW/Pit mode
Frequencytables: 40 CH/37 CH(FCC)/26CH(EU)
Videoformat: PAL / NTSC
Microphone: Built in microphone
Size: 36.5mmx36.5mmx5.5mm
Weight: 9.7g(withoutcable)
Mountingholes: 30.5mmX30.5mm(M3)
