7 EN
2. Remove the protection
caps and connect the
RESET TPS cable (included
in the package) to the
“MAIN” connector of the
SX1 PRO 2T control unit.
As an alternative to the
RESET TPS cable, you can
use the original Wake-
up connector supplied
with the motorcycle
by connecting it to the
diagnosis socket.
3. Connect a fully
charged 12V battery to
the “RESET TPS” cable:
first the red wire to the
positive (+) pole and then
the black wire to the
negative (-) pole.
2 1
4. Rotate the throttle
fully forward to ensure
it is in the closed position
during this operation.
Press and hold the engine
stop button for 5 seconds
or until the GET SX1
Pro 2T ECU turns on the
fuel pump and the MIL
(Malfunction Indicator
Lamp) (when present). By
doing this, the minimum
TPS value is saved.
5 sec.
