GET SX1 PRO 2T - Page 8

8EN
5. Rotate the throttle to
the fully open position.
While holding it open,
press and hold the
engine stop button for
5 seconds or until the
GET SX1 Pro 2T ECU
turns on the fuel pump
and MIL. By doing this,
the maximum TPS value
is saved.
6. Disconnect the wires
from the battery in
reverse order: first the
black wire (-) and then
the red wire (+).
1 2
7. Disconnect the RESET
TPS connector from the
MAIN connector of the
GET SX1 Pro 2T control
unit, put the protection
caps back in place and
start the engine. If
the original Wake-up
connector was used in
point 2, disconnect it from
the diagnosis socket.
5 sec.
