English
3. Slide the lock of the release
latch upwards to the locked
position (
).
Detaching
1. Slide the lock of the release
latch downwards to the
unlocked position (
).
2. Push the release latch toward the right, and
while holding the latch (
), lift K120 out of
the holder (
).
Closing and Opening
Closing
After closing K120, lift the cover latch to
engage it on K120.
CAUTION: Make sure the cover latch is engaged
on K120 while carrying the K120 Tablet and Key-
board Dock set around.
Opening
CAUTION: There is a limit to the tilting angle.
Do not go beyond the limit (120 degrees).
Pry open the cover latch (
) and lift up K120
Tablet (
).
Connecting to Power
More Information
For more information on using the keyboard
and touchpad, refer to the User Manual pro-
vided on K120 Windows desktop.
Safety Instructions
• DO NOT insert any foreign object in any I/O
port.
• DO NOT attempt to make connections if there
is any object between the tablet and the dock.
Doing so could damage the tablet and dock.
• DO NOT place metal objects or containers of
liquid on top of the dock. If metal objects (such
as paper clips and coins) or any liquid spills get
inside the dock, fire or electric shock may result.
Immediately unplug the power cable and re-
move the tablet from the dock.
• Detach the keyboard dock if any of the follow-
ing occurs:
– the dock is damaged
– smoke is emitted
– an unusual smell is emitted
– the dock is unusually hot
Continuing to use the dock while any of the
To Next Page
