GEV CVS 88344 User Manual

9
DGBFNLIESNDKFINRUSGRLVLTPLROSLOSKCZTRH
Technical and design features may be subject to change without notice.
Troubleshooting
Technical information
Problem Check point
No power
(no picture on monitor)
•Isthepowersupplyconnectedcorrectly?
Power is on, but no picture on the
monitor
•Isthecablermlyconnectedbetweenthemonitorandthe
 camera?
•Isthepolarityofwirescorrectbetweentheoutdoorcamera
 unitandindoormonitorunit?
The picture is too dark or white •Adjustbrightnesscontrol
Chime sound is too low •Adjustthevolumecontrol
Indoor unit (8834401) Specifications
Input power DC 17 V
(External power supply)
Power consumption Idle mode: 2 W Operating: max 14 W
Connecting system 2 wires: 2 Cameras, 2 Monitors
Call sounds 4
Max. distance and wiring Monitor to camera
50 M: 1.0 mm² wire
100 M: 1.5 mm² wire
Aspect material Acryl
Display 7 Inch Digital wide screen TFT LCD (LED Backlight)
Operating temperature 0 ˚C to +40 ˚C
Dimensions approx. W 200 x H 150 x D 20 mm
Power Supply Specifications
Current 230 V~, DC 17 V , 1.5 A
Outdoor Unit (8834403) Specifications
Input power DC 12 V from monitor
Power consumption max. 3 W
Material Aluminium
Wiring Monitor: 2 wires Door lock: 2 wires
Image sensor 1/3“ Colour sony super HAD CCD camera
Viewing Angle Diagonal: 90˚ horizontal: 57.8˚ vertical: 48.6˚
Min. illumination 0.5 Lux
Door opener power output max. 12 V /1.0 A
Gate opener dry contact/installed load max. 40 V/ 1.5 A
Mounting type Surface mount
Operating temperature -10 ˚C to +50 ˚C
Dimensions approx. W 95 x H 180 x D 20 mm
MA_1fam_Video_88344_print.indd 9 06.06.14 11:09
