Gewiss RESTART/AUTOTEST - Device Description and Operation; Automatic Operation Overview

22
AUTOMATIC OPERATION
Power supply terminals
(From the meter)
Sliding hatch in the device
cut in position (ON)
Synoptic signal LED
Manual start
of the self-diagnosis
function
Signal and operating
status LED
Auxiliary contact
Output terminals
(To the system)
SELF-DIAGNOSIS AND RESTART FUNCTIONS ACTIVE
DESCRIPTION OF THE RESTART
WITH AUTOTEST DEVICE
