Gewiss RESTART/AUTOTEST - LED Signals; Manual Operation LED Indicators

28
LED SIGNALS
Un 230V ~
In 25 A
I∆n 0,03 A
2 pol.
6.000
63
-25
24
1
3
INSERIRE CON
LEVA IN
POSIZIONE I
ON OFF
I
Un 230V ~
In 25 A
I∆n 0,03 A
2 pol.
6.000
63
-25
24
1
3
INSERIRE CON
LEVA IN
POSIZIONE I
ON OFF
I
Un 230V ~
In 25 A
I∆n 0,03 A
2 pol.
6.000
63
-25
24
1
3
INSERIRE CON
LEVA IN
POSIZIONE I
ON OFF
0
DEVICE FRONT
Manual operation
CONDITION
LEFT
LED
RIGHT
LED
AUXILIARY
CONTACT
Restart and self-diagnosis device not cut in.
Differential switch closed.
System powered up.
Restart and self-diagnosis device not cut in.
Differential switch tripped or opened intentionally.
System not powered up.
Only attempt one manual reclosing before contacting a specialised technician.
Un 230V ~
In 25 A
I∆n 0,03 A
2 pol.
6.000
63
-25
24
1
3
INSERIRE CON
LEVA IN
POSIZIONE I
ON OFF
0
Restart and self-diagnosis device fault.
Call a technician for immediate replacement
of the product. System not powered up.
Restart and self-diagnosis device fault.
Call a technician for immediate replacement
of the product. System powered up.
*
yellow
yellow
*
