ASSEMBLY
STEP 2
Insert the adjustable handle (J) into the hole on the extension tube (D) and tighten with
clockwise rotation.
Position seat cushion (B) as shown and align the the holes on the seat cushion with the
extension tube, connecting the seat cushion and extension tube by using allen key screw with
locking nut (L) , finger tighten with large allen wrench (V) and M8 allen key (U) .
