Schüttelapparate - Shakers
3005 / 3006 / 3011 / 3013 / 3015 / 3016 / 3019 / 3023
Seite 9 Rev5 vom /dated 27.10.2014
The shaker must only be connected to a properly installed power
connection with neuter (PE), according to the local regulations. It
must be secured that power can be cut all-pole (switch or socket).
4. Initiation
Caution,
increased danger of injuries during operation!
Do not reach into the unit during operation!
Caution,
by all means make sure to prevent the shaking procedure
creating an explosive atmosphere
during operation of the shaker!
Before initiation turn the left-hand control knob anti-clockwise to limit stop (minimum
shaking frequency). Then turn right-hand control knob clockwise until the green pilot lamp
glows.
4.1 Choosing the operation mode
For continuous operation turn the knob to the
first scale line; the knob will catch there. To
switch off, turn the knob anti-clockwise to
position 0.
For timed runs turn the control knob past the
scale line for continuous run to the scale
graduation marks for timed runs, showing time
limits in minutes. The maximum timed period is
60 minutes. After expiry of the timed run, the
Shaker will be switched off automatically.
Timed runs chosen by mistake can be reversed
by turning the control knob anti-clockwise.
To switch off the Shaker, turn the control anti-
clockwise to position 0.
4.2 Choosing the shaking frequency
Turn the left-hand control knob
clockwise to increase the
shaking frequency and anti-
clockwise to decrease the
shaking frequency.
The shaking frequency ranges
of all Shaker types are stated
in the Technical Data – item 7
– of these operating
instructions.
