GFW LANCASTER - Parts and Fixings Identification

Side Panel (L)15 + 15 (30) x 335 x 785mm)A 1
B
Side Panel (R)15 + 15 (30) x 335 x 785mm)
1
C
Top Panel (25 x 350 x 790mm)
1
D
Bottom Panel 15 + 15 (30) x 334 x 700mm)
1
E
Shelf (15 x 297 x 700mm)
1
F
Centre Panel (15 x 335 x 168mm)
1
G
Front Bar (15 x 80 x 700mm)
1
H
Rear Bar (15 x 80 x 700mm)
1
I
Bottom Support Bar (15 x 60 x 700mm)
1
J
K
L
Drawer Front (15 x 160 x 335mm)
2
Drawer Front (15 x 160 x 335mm)
2
Door Panel (L) (15 x 345 x 519mm)
1
M
Door Panel (R) (15 x 345 x 519mm)
1
N
Drawer Side (L) (15 x 100 x 300mm)
2
O
Drawer Side (R) (15 x 100 x 300mm)
2
P
Drawer Back (15 x 100 x 287mm)
2
Q
Drawer Side (L) (15 x 115 x 300mm)
1
Y
Back Panel Cabinet (3 x 365 x 736mm)
2
Z
Drawer Bottom (3 x 294 x 296mm)
2
Page 3 of 17
A
G
E
F
B
C
I
D
H
J
Y
Y
L
M
N
Z
P
O
K
N
P
O
