Appendix A Specifications
Voltage Class 115V Class
Model Number VFD-XXXE 002 004 007
Max. Applicable Motor Output
(kW)
0.2 0.4 0.75
Max. Applicable Motor Output (hp) 0.25 0.5 1.0
Rated Output Capacity (kVA) 0.6 1.0 1.6
Rated Output Current (A) 1.6 2.5 4.2
Maximum Output Voltage (V)
3-Phase Proportional to Twice the Input Voltage
Output Frequency (Hz)
0.1~600 Hz
Output Rating
Carrier Frequency (kHz)
1-15
Single-phase
Rated Input Current (A)
6 9 18
Rated Voltage/Frequency Single phase, 100-120V, 50/60Hz
Voltage Tolerance
r
10%(90~132 V)
Input Rating
Frequency Tolerance
r
5%(47~63 Hz)
Cooling Method Natural Cooling Fan Cooling
Weight (kg) 1.2 1.2 1.2
Voltage Class 230V Class
Model Number VFD-XXXE 002 004 007 015 022 037 055 075
Max. Applicable Motor Output
(kW)
0.2 0.4 0.75 1.5 2.2 3.7 5.5 7.5
Max. Applicable Motor Output (hp) 0.25 0.5 1.0 2.0 3.0 5.0 7.5 10
Rated Output Capacity (kVA) 0.6 1.0 1.6 2.9 4.2 6.5 9.5 12.5
Rated Output Current (A) 1.6 2.5 4.2 7.5 11.0 17 25 33
Maximum Output Voltage (V)
3-Phase Proportional to Input Voltage
Output Frequency (Hz)
0.1~600 Hz
Output Rating
Carrier Frequency (kHz) 1-15
Single/3-phase 3-phase
Rated Input Current (A)
4.9/1.9 6.5/2.7 9.5/5.1 15.7/9 24/15 20.6 26 34
Rated Voltage/Frequency
Single/3-phase
200-240 V, 50/60Hz
3-phase
200-240V, 50/60Hz
Voltage Tolerance
r
10%(180~264 V)
Input Rating
Frequency Tolerance
r
5%(47~63 Hz)
Cooling Method Natural Cooling Fan Cooling
Weight (kg) 1.1 1.1 1.1 1.9 1.9 1.9 3.5 3.5
