Appendix D How to Use PLC Function
VFD-E Series
Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03 D-23
Special
D
Function
Read(R)/
Write(W)
D1029
The value of ACI (analog current input) 4-20mA corresponds to 0-1023 or the
value of AVI2 (analog voltage input) 0-10V corresponds to 0-1023
R
D1030 The value of V.R digital keypad 0-10V corresponds to 0-1023 R
D1031-
D1035
Reserved --
D1036 PLC error code R
D1037-
D1039
Reserved --
D1040 Analog output value R/W
D1041-
D1042
Reserved --
D1043
User defined (when Pr.00.04 is set to 2, the register data will be displayed as
C xxx)
R/W
D1044 High-speed counter mode R/W
D.6.11 Communication Addresses for Devices (only for PLC2 mode)
Device Address Device Address Device Address
X0 0400H Y0 0500H T0~T15 0600H~060FH
X1 0401H Y1 0501H M0~M159 0800H~089FH
X2 0402H Y2 0502H M1000~M1031 0BE8H~0C07H
X3 0403H Y3 0503H C0~C7 0E00H~0E07H
X4 0404H Y4 0504H D0~D63 1000H~101DH
X5 0405H Y5 0505H D1000~D1044 13E8H~1414H
X6 0406H Y6 0506H
-- --
X7 0407H Y7 0507H
-- --
X10 0408H Y10 0508H
-- --
X11 0409H Y11 0509H
-- --
X12 040AH Y12 050AH
-- --
X13 040BH Y13 050BH
-- --
X14 040CH Y14 050CH
-- --
X15 040DH Y15 050DH
-- --
X16 040EH Y16 050EH
-- --
X17 040FH Y17 050FH
-- --
