Chapter 5 Parameters
_
VFD-E Series
Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03 5-5
Parameter Explanation Settings
Factory
Setting
Customer
02.08
Accel/Decel Rate of
Change of
UP/DOWN
Operation with
Constant Speed
0.01~10.00 Hz 0.01
a02.09
Source of Second
Frequency
Command
0: Digital keypad UP/DOWN keys or Multi-
function Inputs UP/DOWN. Last used
frequency saved.
1: 0 to +10V from AVI
2: 4 to 20mA from ACI or 0 to +10V from
AVI2
3: RS-485 serial communication (RJ-45).
4: Digital keypad potentiometer
0
0: First Master Frequency Command
1: First Master Frequency Command+
Second Master Frequency Command
a02.10
Combination of the
First and Second
Master Frequency
Command
2: First Master Frequency Command -
Second Master Frequency Command
0
a02.11
Keyboard Frequency
Command
0.00 to 600.0Hz
60.00
a02.12
Communication
Frequency
Command
0.00 to 600.0Hz
60.00
0: Save Keypad & Communication Frequency
1: Save Keypad Frequency only
02.13
The Selections for
Saving Keypad or
Communication
Frequency
Command
2: Save Communication Frequency only
0
0: by Current Freq Command
1: by Zero Freq Command
02.14
Frequency
Command
Selections at Stop
(for Keypad and
Communication)
2: by Frequency Display at Stop
0
02.15
Frequency Display at
Stop
0.00 ~ 600.0Hz 60.00
02.16
Display the Master
Freq Command
Source
Read Only
Bit0=1: by First Freq Source (Pr.02.00)
Bit1=1: by Second Freq Source (Pr.02.09)
Bit2=1: by Multi-input function
Bit3=1: by PLC Freq command
##
02.17
Display the
Operation Command
Source
Read Only
Bit0=1: by Digital Keypad
Bit1=1: by RS485 communication
Bit2=1: by External Terminal 2/3 wire mode
Bit3=1: by Multi-input function
Bit4=1: by PLC Operation Command
##
Group 3 Output Function Parameters
Parameter Explanation Settings
Factory
Setting
Customer
03.00 Multi-function Output
0: No function
8
