Chapter 5 Parameters
_
VFD-E Series
5-16 Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03
Parameter Explanation Settings
Factory
Setting
Custome
r
0: By PID control
10.17
Minimum PID Output
Frequency Selection
1: By minimum output frequency (Pr.01.05)
0
Group 11 Parameters for Extension Card
Parameter Explanation Settings
Factory
Setting
Customer
0: No function
1: AC drive operational
2: Master frequency attained
11.00
Multi-function Output
Terminal MO2/RA2
3: Zero speed
0
4: Over torque detection
5: Base-Block (B.B.) indication
6: Low-voltage indication
11.01
Multi-function Output
Terminal MO3/RA3
7: Operation mode indication
0
8: Fault indication
9: Desired frequency attained
10: Terminal count value attained
11.02
Multi-function Output
Terminal MO4/RA4
11: Preliminary count value attained
0
12: Over Voltage Stall supervision
13: Over Current Stall supervision
14: Heat sink overheat warning
11.03
Multi-function Output
Terminal MO5/RA5
15: Over Voltage supervision
0
16: PID supervision
17: Forward command
18: Reverse command
11.04
Multi-function Output
Terminal MO6/RA6
19: Zero speed output signal
0
20: Warning(FbE,Cexx, AoL2, AUE, SAvE)
11.05
Multi-function Output
Terminal MO7/RA7
21: Brake control (Desired frequency
attained)
0
0: No function
0
1: Multi-Step speed command 1
11.06
Multi-function Input
Terminal (MI7)
2: Multi-Step speed command 2
3: Multi-Step speed command 3 0
4: Multi-Step speed command 4
11.07
Multi-function Input
Terminal (MI8)
5: External reset
6: Accel/Decel inhibit 0
7: Accel/Decel time selection command 11.08
Multi-function Input
Terminal (MI9)
8: Jog Operation
9: External base block 0
10: Up: Increment master frequency
11.09
Multi-function Input
Terminal (MI10)
11: Down: Decrement master frequency
