C. Place the transmitter next to Control Unit on left side with the remote transmitter LEARN button located
closest to the left side of the Vehicle Sensor Control Board.
(Shown below, Step 2C)
D. On the transmitter, PRESS and HOLD DOWN the button on remote transmitter (typically the large button
with the single GC logo) that controls the gate.
(Shown below, Step 2D)
E. The RED “LEARN” LED on the Control Unit Board should go OFF indicating the signal is “LEARNED”.
3. TESTING THE SENSOR PROBE:
A. Move some type of steel object like a large screw driver along the vehicle sensor (as shown below in Step 3A).
RED LED light on Control
Unit should go OFF. Now you
can OPEN your gate with
vehicle sensor.
Step 2C
Step 2D
Vehicle Sensor
Step 3A
Screwdriver or other metal object
Move screwdriver this way
This remote transmitter
button currently opens
the gate. Press and
HOLD this button until
RED LED on Control
Unit goes out.
Learn button on
remote transmitter
closest to left edge of
Control Unit Board.
DO NOT press this
“Learn” button.
Learn LED ON
