c
. Insert the jumper into 2-3
3. Clear all PINs:
a. Reset Master Code to default value (5 beeps, clearing all PINs)
b. Insert the jumper into 2-3
Enter Setting Mode
Enter the master code twice (Default value: “1234” or “12345) to enter setting mode (2 beeps)
Note: 1. After 60 seconds if no data entered, it will automatically exit the setting mode.
2. The controller will be locked for 60 seconds upon 30 consecutive master codes
attempt.
Add new PINs (In setting mode)
1. Enter Master code twice (2 beeps)
2. Slot position ＊01~＊21
3. Enter the PINs (1 beep)
4. Repeat, or press “#” to exit setting mode
Relay 1 is controlled by the slot position ＊01~＊20
Relay 2 is controlled by the slot position ＊21
Note: “00000”, “1234”, “12345” and master code cannot be used for PINs.
Set the Relay Strike Time (In setting mode)
1. Enter the master code twice (2 beeps)
2. Press ＊30 (or ＊31)
3. Press 05 (01~99) (1 beep)
Press 05 will set the relay strike to 5 seconds, relay set to toggle mode by press “00”
4. Press “#” to exit setting mode
Note: In Toggle mode, the relay will switch between N.C. contact and N.O. contact by input
PIN once.
Delete PINs (In setting mode)
1. Enter the master code twice (2 beeps)
2. Press ＊06 (e.g. code to delete)
3. Press 0000 (or 00000) (1 beep)
4. Press “#” to exit setting mode
Change Master Code (In setting mode)
1. Enter the master code twice (2 beeps)
2. Press＊00
3. Enter new master code (1 beep)
4. Press “#” to exit setting mode
