3
H/bar stem height &
angle adjustment
procedure
Put it in correct position
before you ride
Loose stem clamp bolt with 6mm Allen key,
pull the quill to your desired height, and
then tighten the clamp bolt.
Maximum tighten force: 10 N-m.
Caution:
The Minimum Insertion mark of stem and
seat post should NOT be visible.
It is essential to thoroughly check that
your bars and stem are tight and cannot
be moved after you have made any
adjustments.
Please make sure all the quick release and
bolt are probably tighten before your ride.
WARNINGS !
Open handlebar quick release, rotate
handlebar to your desired position and
tighten the quick release securely.
