GiBiDi BE24 User Manual

20
BE24
UK
11 - DIP SWITCH DIP3
Transmitter button 1.
3_1
3_2
OFF
OFF
START COMMAND
ALLOCATION TO
TRANSMITTER
BUTTON
DescriptionDIP
Status
Function
OFF
ON
Transmitter button 2.
ON
OFF
Transmitter button 3.
ON
ON
Transmitter button 4.
3_3
3_4
OFF
OFF
PEDESTRIAN
COMMAND
ALLOCATION TO
TRANSMITTER
BUTTON
OFF
ON
ON
OFF
ON
ON
If this setting is the same as
DIP3_1 and DIP3_2,
PEDESTRIAN is disabled.
3_5
OFFUNUSED
3_6
ON
OFF
UNUSED
Keep this OFF, do not change.
In order to store the new settings It’s necessary to power down and power up the control board.
The default settings are highlighted in the boxes with grey background.
Transmitter button 1.
Transmitter button 2.
Transmitter button 3.
Transmitter button 4.
12 - ONBOARD RADIO RECEIVER CONTROL
Storing a new transmitter in memory:
1 - Press and release Learn button.
2 - Led L6 will come on.
3 - Press button 1 of the transmitter to be stored for 2 seconds.
4 - The new transmitter is stored.
5 - Led L6 will stay on for another 5 seconds; during this period, you can store other transmitters, restarting from
step 3.
It is possible to store up to 200 transmitters.
Clearing the memory:
1 - Press and hold down Learn button for 12 seconds.
2 - Led L6 will initially come on and then go off after 12 seconds.
3 - All the transmitters have now been deleted.
Assigning START and PED commands to the transmitter buttons:
Refer to Figure 17-18 and DIP3 configuration.
