28
BE24
DescriptionDIP
Etat
Fonction
9 - DIP SWITCH DIP1
Les positions sont mémorisées pendant la phase de repos (portail fermé).
Les positions par DEFAUT sont indiquées dans la case grise
OFF
PAS – PAS
AVEC STOP
ON
COPROPRIETE
Fonctionnement en réponse à la commande de START :
Ÿ Portail fermé OUVRE
Ÿ Pendant l’ouverture STOP
Ÿ Portail ouvert FERME
Ÿ Pendant la fermeture STOP
Ÿ Après un STOP inverse le mouvement
Fonctionnement en réponse à la commande de START :
Ÿ Portail fermé OUVRE
Ÿ Pendant l’ouverture PAS INFLUENT
Ÿ Portail ouvert Recharge le temps de fermeture automatique si la
refermeture automatique est habilitée, au contraire ferme.
Ÿ Pendant la fermeture OUVRE
OFF
ON
BORNE 21 COMME
BORD SENSIBLE 8K2
Fonctionnement :
Ÿ Portail fermé
Ÿ Pendant l’ouverture STOP
Ÿ Portail ouvert STOP, pas de refermeture automatique
Ÿ Pendant la fermeture STOP
Ÿ Après un STOP inverse le mouvement
PAS INFLUENT
Fonctionnement :
Ÿ Portail fer PAS INFLUENT
Ÿ Pendant l’ouverture Inversion immédiate du mouvement par 2s
ralentissant et, après liberation du contact, inversion totale avec mouvement ralenti.
Ÿ Portail ouvert PAS INFLUENT
Ÿ Pendant la fermeture Inversion immédiate du mouvement par 2s
ralentissant et, quand le contast est libéré, inversion totale avec mouvement ralenti.
1_1
1_2
BORNE 21 COMME
STOP 8K2
1_3
1_4
SEUIL
ANTI-ECRASEMENT
Sensibilité très élevée
OFF
OFF
Sensibilité élevée
OFF
ON
Sensibilité moyenne
ON
OFF
Sensibilité basse
ON
ON
1_5
1_6
TEMPS PAUSE
Fermeture automatique désactivée
OFF
OFF
30 s
OFF
ON
60 s
ON
OFF
120 s
ON
ON
