PASS
11
PRELIMINARY WARNINGS
ELECTRICAL EQUIPMENT
ELECTRICAL EQUIPMENT
UK
1- Gearmotor: power supply, (comply with the current standards)
2- Photocell transmitter 2x0.5mm² cable
3- Photocell receiver 4x0.5 mm² cable
4- Antenna screened coaxial cable.
5- Frame 4x0.5mm² cable
6- Rack
7- Key selector 3x0.5mm² cable
8- 230 Vac flashing light signaller 2x0.75mm² cable
9- Omnipolar magnetothermal switch with minimum contact opening of 3 mm. Power supply line to the control
unit: 220-230V, 50-60Hz, 3x1.5mm² (comply with the current standards).
3x1.5mm²
cable
Supply Voltage
Power adsorbed
Current adsorbed
Thermal cutout
Capacitor
Max speed
Max torque
Operating temperature
Degree of protection
Max leaf weight
Operator
Type
Oil
Formula to calculate the
operating frequency
[21]
Operating frequency (%)
Check that the gate structure is in conformity with the regulations in force and that leaf movement is linear without
friction.
Preliminary checks:
check that the gate structure is sufficiently robust. In any case, check that the weight and dimensions of the gate
fall within the limits of use of the operator;
check that the leaf can be moved manually without force (points of greatest friction) for the entire travel of the gate
during both opening and closing;
PASS 600
PASS 800
220/230Vac 50-60Hz
350W
MAX 1.5A
0,15 m/sec
22 N/m
IP 55
-20°C + 60°C
800 Kg
140°C
10µF
GBD PH-02
60% (20°C)
Electronic
Electronic and Mechanical
Torque regulation
Irreversible electromechanical gearmotor
A = Opening time
C = Closing time
P = Overall pause time
A+C+P = Time between two openings
%Fu = x 100
A + C
A + C + P
