GiBiDi SC230 Instructions For Installations

SC230
DESRCIZIONE MENU ( A ) 12 - MANUAL MANOEUVRE
If the gate is unlocked and moved manually, with the electronic card powered, the control unit is reset and the following movement
will be an opening.
Position the gate into the stroke defined by the limit switches before locking the operator again.
DESRCIZIONE MENU ( A ) 13 - FINAL CHECKS
ŸCheck the electrical connections: an improper connection may be harmful to both the control unit and the operator.
ŸCheck the correct position of the limit switches.
ŸAlways preset the mechanical stops in opening and closing.
ŸCheck the correct operation of photocells and safety devices.
ŸCheck that the motors are blocked and ready to work with GATE HALFWAY POSITION.
ŸRemove possible obstacles in the operating area of the gate.
ŸCheck that the direction of gate motion is correct:
§take off the power supply from the control unit.
§power the control unit.
§give a START command.
§check that the gate is opening, otherwise take off the power supply from the control unit and invert the wires of terminal
M2
ŸCheck the correct operation of the automation.
DESRCIZIONE MENU ( A ) 14 - FLASHING LIGHT SIGNALLING SUMMARY
Device Signalling Effect
Photo intercepted at rest in presence of START
command ( DIP5 = ON )
5 fast flashings
When released, it opens
Frame intercepted before the motion
3 slow flashings
Door blocked
Test photo failed
4 slow flashings
Door blocked
Test frame 8K2 Failed (terminal 11) 2 slow flashings
Door blocked
Test frame 8K2 Failed (terminal 12)
1 slow flashing
Door blocked
UK
16
