Function 24 Piezo PU (right channel) PEQ settings: Configure EQ gain Default depends on sound
Result Clickstream
Configure gain for the magnetic pickups' 4-band PEQ 24
§ coil configuration number
§ band number § gain data
Example: To configure the left channel, PEQ Band1 gain for the Gibson Classic sound, use the clickstream 24 § 0 § 1 § 0.
You need the Dark Fire Configuration Tool to calculate the correct gain data.
Function 30 Set stepper speed: Determine maximum speed for individual Powerheads Default = 5
Value Result Clickstream
0-9 Set seach Powerhead's maximum speed (0 = slowest, 9 = fastest) 30 § 1 § 5 §
Note: The second clickstream number is the associated Powerhead number, the third clickstream number is the speed
Function 31 Max concurrent steppers: Max number of Powerheads running simultaneously Default = 6
Value Result Clickstream
1-6 Set number of Powerheads that can tune at the same time 30 § 1-6 §
Note: The third clickstream number can range from 1 to 6
Function 32 Stepper acceleration: Set acceleration for each Powerhead individually Default = 5
Value Result Clickstream
0-9 Sets Powerhead acceleration 32 § 1 § 0-9 §
Note: The second clickstream number is the associated Powerhead number, the third number is the acceleration
Function 37 Set maximum speed for all Powerheads: Adjusts all Powerheads at once Default = 5
Value Result Clickstream
0-9 Sets maximum speed for all Powerheads, not just individual ones 37 § 0-9 §
Note: 0 is the slowest speed, 9 is the fastest speed
Function 38 Set acceleration for all Powerheads: Adjusts all Powerheads at once Default = 5
Value Result Clickstream
0-9 Sets acceleration for all Powerheads, not just individual ones 38 § 0-9 §
Note: 0 is the slowest acceleration, 9 is the fastest acceleration
Gibson Dark Fire 4.0 manual, page 34
