A-2: Installation in Intel RST Premium With Intel Optane System Acceleration mode
If the SATA controller has been congured in Intel RST Premium With Intel Optane System Acceleration mode,
please follow the steps below:
1. After system restarts, go to the BIOS Setup, make sure CSM Support under the BIOS menu is disabled.
2. Go to Peripherals\SATAAndRSTConguration and make sure Use RST Legacy OROM is disabled. If
you want to enable the Optane
memory installed in the M2A connector, set PCIe Storage Dev On Port 9
to RST Controlled.
3. Enter the operating system, launch the Intel
®
Rapid Storage Technology utility from the Start menu, and then
enable Intel
®
Optane
Memory on the Intel
®
Optane
Memory screen.
4. Then select which drive to be accelerated. Click Yes to continue. Follow the on-screen instructions to proceed.
When completed, restart the system.
5. Launch the Intel
®
Rapid Storage Technology utility from the Start menu and make sure the Intel
®
Optane
Memory has been enabled. If you want to accelerate the system drive, you can select specic folders, les, or
applications to accelerate using the Intel
®
Optane
Memory Pinning function. (The Intel
®
Optane
memory
used must have at least 32 GB capacity.)
An Optane
memory cannot be used to accelerate an M.2 PCIe SSD.
Do not abruptly remove the Optane
memory. Doing so will cause the operating system to stop
functioning correctly.
If you want to change/remove the Optane
memory, you must disable it using the Intel
®
Rapid
Storage Technology or Intel(R) Optane
Memory application rst.
After enabling the Optane
memory, the related BIOS settings will remain even after a BIOS update.
