Gigabyte B450 AORUS PRO WIFI User Manual

Storage Interface  1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe
3.0x4/x2SSDsupport)(M2A_SOCKET)
 1 x M.2 connector (Socket3, M key,type2242/2260/2280 PCIe 3.0x2 SSD
support)(M2B_SOCKET)
 6 x SATA 6Gb/s connectors
 SupportforRAID0,RAID1,andRAID10
* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
USB  Chipset:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 2 support
- 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
- 2 x USB 3.1 Gen 1 ports available through the internal USB header
- 4 x USB 2.0/1.1 ports available through the internal USB headers
 CPU:
- 4 x USB 3.1 Gen 1 ports on the back panel
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 2 x M.2 Socket 3 connectors
 6 x SATA 6Gb/s connectors
 1 x CPU fan header
 1 x water cooling CPU fan header
 2 x system fan headers
 1 x system fan/water cooling pump header
 1xCPUcoolerLEDstrip/RGBLEDstripheader
 2xdigitalLEDstripheaders
 2xdigitalLEDstrippowerselectjumpers
 1xRGB(RGBW)LEDstripheader
 1 x front panel header
 1 x front panel audio header
 1xS/PDIFOutheader
 1 x USB 3.1 Gen 1 header
 2 x USB 2.0/1.1 headers
 1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module
only)
 1 x Clear CMOS jumper
Back Panel
Connectors
 1xHDMIport
 2 x SMA antenna connectors (1T1R)
(Note)
 1xDVI-Dport
 4 x USB 3.1 Gen 1 ports
 1 x USB Type-C
™
port, with USB 3.1 Gen 2 support
 1 x USB 3.1 Gen 2 Type-A port (red)
 1 x RJ-45 port
 1xopticalS/PDIFOutconnector
 5 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Water cooling ow rate detection
(Note) Only for the B450 AORUS PRO WIFI.
- 8 -

Gigabyte B450 AORUS PRO WIFI Specifications

General

Wi-Fi	Yes
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	AMD B450
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard chipset family	AMD
Windows operating systems supported	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 7 Enterprise x64, Windows 7 Home Basic x64, Windows 7 Home Premium x64, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate x64, Windows 7 x64
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200 MHz
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	16384 MB
Parallel processing technology support	2-Way CrossFireX, Quad-GPU CrossFireX
Processor socket	Socket AM4
Compatible processor series	AMD Athlon, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors	1
Number of M.2 (M) slots	2
PCI Express x16 (Gen 3.x) slots	3
RAID levels	0, 1, 10
Number of HDDs supported	6
Supported storage drive types	HDD & SSD
HDD size	2.5/3.5 \
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	32 Mbit
Desktop Management Interface (DMI) version	2.7
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables included	SATA
Bundled software	Norton Internet Security (OEM version) cFosSpeed

Weight and Dimensions

Depth	244 mm
Width	305 mm
