2-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN1
5) LED_CPU
6) LED_C
7) D_LED1/D_LED2
8) SATA3 0/1/2/3
9) M2A_SOCKET
10) SPDIF_O
11) F_ PANEL
12) F_ AUDIO
13) F_USB30
14) F_USB1
15) COM
16) TPM
17) BAT
18) CLR_CMOS
1
2
3
13
5
712 6
9
4
8
14 1118
17
10
7
15
16
- 13 -
