Gigabyte B450M DS3H WIFI User Manual

Storage Interface  1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe
(Note)
3.0 x4/x2 SSD support)
 4 x SATA 6Gb/s connectors
 Support for RAID 0, RAID 1, and RAID 10
USB  CPU:
- 4 x USB 3.1 Gen 1 ports on the back panel
 Chipset:
- 2 x USB 3.1 Gen 1 ports available through the internal USB header
- 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through
the internal USB header)
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 1 x system fan header
 1 x CPU cooler LED strip/RGB LED strip header
 1 x RGB LED strip header
 2 x addressable LED strip headers
 1 x M.2 Socket 3 connector
 4 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1 x S/PDIF Out header
 1 x USB 3.1 Gen 1 header
 1 x USB 2.0/1.1 header
 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S
module only)
 1 x serial port header
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 1 x HDMI port
 4 x USB 3.1 Gen 1 ports
 4 x USB 2.0/1.1 ports
 2 x SMA antenna connectors (1T1R)
 1 x RJ-45 port
 3 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Overheating warning
 Fan fail warning
 Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
- 8 -

Gigabyte B450M DS3H WIFI Specifications

General

Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen
Supported processor sockets	Socket AM4
Maximum number of SMP processors	1
Maximum internal memory supported by processor	128 GB
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3466, 3600 MHz
Supported memory clock speed (max)	3600 MHz
Supported memory module capacities	4GB, 8GB, 16GB, 32GB
Wi-Fi standards	802.11a, 802.11ad, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Realtek RTL8821CE
Ethernet interface type	Gigabit Ethernet
USB 2.0 connectors	2
Number of Parallel ATA connectors	0
USB connector type	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Number of storage drives supported	5
Supported storage drive interfaces	M.2, SATA III
Bundled software	Norton Internet Security, cFosSpeed
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	128 Mbit
System Management BIOS (SMBIOS) version	2.7
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	16000 MB
Parallel processing technology support	Not supported
Audio chip	Realtek ALC887
Component for	PC
Product color	Brown
Power source type	ATX
Motherboard chipset	AMD B450
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10 x64, Windows 7 x64
Warranty period	3 year(s)
Battery type	CR2032
Battery weight	3 g
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Country of origin	China
Quantity per shipping (inner) case	1 pc(s)
Package width	265 mm
Package height	54 mm
Package weight	950 g

Weight and Dimensions

Height	35 mm
