Storage Interface  1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key,
type 2242/2260/2280/22110 SSDs:
- 3rdGenerationAMDRyzen
™
processors support SATA and PCIe 4.0 x4/x2 SSDs
- 3rdGenerationAMDRyzen
™
withRadeon
™
Graphics processors support
SATA and PCIe 3.0 x4/x2 SSDs
 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3,
M key, type 2242/2260/2280 SSDs:
- Supporting SATA and PCIe 3.0 x2 SSDs
 4 x SATA 6Gb/s connectors, integrated in the Chipset:
- SupportforRAID0,RAID1,andRAID10
USB  CPU:
- 4 x USB 3.2 Gen 1 ports on the back panel
 Chipset:
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
- 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through
the internal USB header)
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 2 x system fan headers
 2 x addressable LED strip headers
 2xRGBLEDstripheaders
 1xCPUcoolerLEDstrip/RGBLEDstripheader
 2 x M.2 Socket 3 connectors
 4 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1 x USB 3.2 Gen 1 header
 1 x USB 2.0/1.1 header
 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S
module only)
 1 x serial port header
 1 x Clear CMOS jumper
 1 x Q-Flash Plus button
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 1 x DVI-D port
 1 x HDMI port
 4 x USB 3.2 Gen 1 ports
 4 x USB 2.0/1.1 ports
 1xRJ-45port
 3 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
