B560 HD3 Motherboard Layout
Box Contents
5 B560 HD3 motherboard 5 Two SATA cables
5 Motherboard driver disc 5 I/O Shield
5 User's Manual 5 M.2 screw(s)
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
KB_MS_USB
DP_HDMI
U32
U32_LAN
LGA1200
ATX
AUDIO
DDR4_A1 DDR4_A2 DDR4_B1 DDR4_B2
ATX_12V_2X4
Intel
®
B560
CLR_CMOS
M_BIOS
PCIEX1_1
PCIEX4
PCIEX16
PCIEX1_2
F_U32
M2A_SB
CODEC
B560 HD3
SYS_FAN3
SPI_TPM F_PANEL
SPDIF_O
F_AUDIO
COM
LPT
LED_C1
D_LED1
SYS_FAN1
SYS_FAN2
THB_C1
CPU_FAN
CPU_OPT
iTE
®
Super I/O
BAT
Realtek
®
GbE LAN
SATA3
5 3 1 4 2 0
THB_C2
M2P_CPU
1108060
6080110
F_USB1F_USB3
F_USB2
DVI
VGA
QFLASH_PLUS
QFLED
USB 2.0 Hub
Temperature
sensor
