- 3 -

Table of Contents

B560I AORUS PRO AX Motherboard Layout ..................................................................4

B560I AORUS PRO AX Motherboard Block Diagram .....................................................5

Chapter 1 Hardware Installation .....................................................................................6

1-1 Installation Precautions .................................................................................... 6

1-2 Product Specications ...................................................................................... 7

1-3 Installing the CPU .......................................................................................... 10

1-4 Installing the Memory ..................................................................................... 10

1-5 Installing an Expansion Card ......................................................................... 11

1-6 Back Panel Connectors .................................................................................. 11

1-7 Internal Connectors ........................................................................................ 13

Chapter 2 BIOS Setup ..................................................................................................20

2-1 Startup Screen ............................................................................................... 20

2-2 The Main Menu .............................................................................................. 21

2-3 Smart Fan 6 .................................................................................................. 22

2-4 Favorites (F11) ............................................................................................... 23

2-5 Tweaker .......................................................................................................... 24

2-6 Settings .......................................................................................................... 29

2-7 System Info. ................................................................................................... 33

2-8 Boot ................................................................................................................ 34

2-9 Save & Exit ..................................................................................................... 37

Chapter 3 Appendix ......................................................................................................38

3-1 Installing Intel

Optane

™

Memory and Storage Management ........................ 38

3-2 Drivers Installation .......................................................................................... 39

Regulatory Notices .................................................................................................... 40

Contact Us ................................................................................................................ 44

Questions and Answers:

Need help?

Do you have a question about the Gigabyte B560I AORUS PRO AX and is the answer not in the manual?

Gigabyte B560I AORUS PRO AX Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2933, 3000, 3200 MHz
Supported storage drive types	HDD & SSD
Number of storage drives supported	6
Supported storage drive interfaces	M.2, SATA III
Maximum resolution	4096 x 2304 pixels
Parallel processing technology support	Not supported
USB 2.0 connectors	1
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Headphone outputs	3
USB connector type	USB Type-A, USB Type-C
DisplayPort version	1.2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.1
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX200
Ethernet interface type	2.5 Gigabit Ethernet
Component for	PC
Motherboard chipset	Intel B560 Express
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Windows operating systems supported	Windows 10 x64
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	256 Mbit
Desktop Management Interface (DMI) version	2.7
Bundled software	Norton Internet Security, cFosSpeed
Harmonized System (HS) code	84733020
