Gigabyte B560M D2V - Storage and USB Interface Specifications; Internal and Back Panel Connector Overview; I;O Controller Information

Storage Interface  CPU:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD
support) (M2P_CPU)
(Note)
 Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0
x4/x2 SSD support) (M2A_SB)
- 6 x SATA 6Gb/s connectors
* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
 Intel
®
Optane
™
Memory Ready
* System acceleration with Intel
®
Optane
™
Memory can only be enabled on the
M2P_CPU connector and with an 11th Generation Intel
®
processor installed.
USB  Chipset:
- 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through
the internal USB header)
 Chipset+USB 2.0 Hub:
- 8 x USB 2.0/1.1 ports (2 ports on the back panel, 6 ports available through
the internal USB headers)
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 1 x system fan header
 1 x addressable LED strip header
 1 x RGB LED strip header
 2 x M.2 Socket 3 connectors
 6 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1 x USB 3.2 Gen 1 header
 3 x USB 2.0/1.1 headers
 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI
2.0 module only)
 1 x serial port header
 1 x Clear CMOS jumper
 1 x Q-Flash Plus button
Back Panel
Connectors
 1 x PS/2 mouse port
 1 x PS/2 keyboard port
 1 x D-Sub port
 1 x DVI-D port
 4 x USB 3.2 Gen 1 ports
 2 x USB 2.0/1.1 ports
 1 x RJ-45 port
 3 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
(Note) Supported by 11th Generation processors only.
- 7 -
