- 4 -
1-1 Motherboard Layout
Chapter 1 Product Introduction
VGA
(Note)
CPU_FAN
ATX
B650M H
B650M S2H
F_AUDIO
AUDIO
BAT
ATX_12V
CODEC
CLR_CMOS
USB_LAN
PCIEX16
iTE
®
Super I/O
Realtek
®
GbE LAN
SPI_TPM F_USB1 F_PANEL
SYS_FAN1F_USB2
SATA3
1 0
3 2
U32
80
M_BIOS
D_LED
LED_C
QFLASH_PLUS
F_U32
DP_HDMI
M2A_CPU
DDR5_B1
DDR5_A1
SYS_FAN2
QFLED
PCIEX1
KB_MS_USB
Socket AM5
AMD
Chipset
Temperature sensor
(Note) Only for B650M S2H.
ESPI_DB
