Back Panel
Connectors
 1 x USB Type-C
®
port, with USB 3.2 Gen 2x2 support
 1 x USB 3.2 Gen 2 Type-A port (red)
 3 x USB 3.2 Gen 1 ports
 4 x USB 2.0/1.1 ports
 2 x SMA antenna connectors (2T2R)jl
 1 x HDMI port
 1 x DisplayPort
 1 x RJ-45 port
 1 x optical S/PDIF Out connector
 2 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Water cooling ow rate detection
 Fan fail warning
 Fan speed control
* Whether the fan (pump) speed control function is supported will depend on the fan
(pump) you install.
BIOS  1 x 256 Mbit ash
 Use of licensed AMI UEFI BIOS
 PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features  Support for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions
of each application may also vary depending on motherboard specications.
 Support for Q-Flash
 Support for Q-Flash Plus
Bundled
Software
 Norton
®
Internet Security (OEM version)
 LAN bandwidth management software
Operating
System
 Support for Windows 11 64-bit
 Support for Windows 10 64-bit
Form Factor
 Micro ATX Form Factor; 24.4cm x 24.4cm
* GIGABYTE reserves the right to make any changes to the product specications and product-related information without
prior notice.
& Please visit GIGABYTE's website for support lists of CPU, memory modules, SSDs, and M.2 devices.
https://www.gigabyte.com/Motherboard/B760M-AORUS-PRO-AX-rev-10?m=dl#support-dl
https://www.gigabyte.com/Motherboard/B760M-AORUS-PRO-rev-10?m=dl#support-dl
https://www.gigabyte.com/Motherboard/B760M-AORUS-PRO-AX-DDR4-rev-10?m=dl#support-dl
https://www.gigabyte.com/Motherboard/B760M-AORUS-PRO-DDR4-rev-10?m=dl#support-dl
& Please visit the SERVICE/SUPPORT\Utility page on GIGABYTE's website to download the latest
version of apps.
https://www.gigabyte.com/Support/Utility/Motherboard?m=ut
j Only for B760M AORUS PRO AX.
l Only for B760M AORUS PRO AX DDR4.

Gigabyte B760M AORUS PRO AX Specifications

General

Form Factor	Micro ATX
Chipset	Intel B760
Socket	LGA 1700
Memory Type	DDR5
Maximum Memory	128GB
Memory Slots	4
Audio	Realtek ALC897
PCIe Slots	1 x PCIe 4.0 x16, 1 x PCIe 3.0 x16 (x4 mode), 1 x PCIe 3.0 x1
Storage Interface	4 x SATA 6Gb/s
USB Ports	1 x USB Type-C
Networking	Intel Wi-Fi 6E AX211, Intel 2.5GbE LAN
RGB Headers	2 x addressable LED strip headers 2 x RGB LED strip headers
Memory Speed	DDR5-7600+ (OC)
