Gigabyte B760M C User Manual

- 7 -
Expansion Slots  CPU:
- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)
(PCB rev. 1.1)
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
(PCB rev. 1.0)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
 Chipset:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4)
- 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1
(PCIEX1_1, PCIEX1_2)
Storage Interface  CPU:
- 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD
support) (M2A_CPU)
 Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support)
(M2P_SB)
- 2 x M.2 connectors (Socket 3, M key, type 2280 PCIe 3.0 x1 SSD support)
(M2Y_SB, M2X_SB)
- 4 x SATA 6Gb/s connectors
 RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
USB  Chipset:
- 1 x USB Type-C
®
port on the back panel, with USB 3.2 Gen 2x2 support
- 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
- 1 x USB Type-C
®
port with USB 3.2 Gen 1 support, available through the
internal USB header
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
 Chipset+USB 2.0 Hub:
- 10 x USB 2.0/1.1 ports (4 ports on the back panel, 6 ports available through
the internal USB headers)
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 3 x system fan headers
 2 x addressable LED strip headers
 2 x RGB LED strip headers
 4 x M.2 Socket 3 connectors
 4 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1 x speaker header
 1 x USB Type-C
®
header, with USB 3.2 Gen 1 support
 1 x USB 3.2 Gen 1 header
 3 x USB 2.0/1.1 headers
 2 x Thunderbolt
™
add-in card connectors
 1 x Q-Flash Plus button
 1 x reset jumper
 1 x Clear CMOS jumper
 1 x chassis intrusion header

Gigabyte B760M C Specifications

General

Form Factor	Micro ATX
Chipset	Intel B760
Socket	LGA 1700
Memory Type	DDR5
Maximum Memory	128 GB
Memory Slots	4
Video Outputs	1 x HDMI, 1 x DisplayPort
PCIe Slots	1 x PCIe 3.0 x16 (x4 mode), 1 x PCIe 3.0 x1
Storage Interface	4 x SATA 6Gb/s
USB Ports	1 x USB 3.2 Gen 2x2 Type-C, 1 x USB 3.2 Gen 2 Type-A, 2 x USB 3.2 Gen 1, 4 x USB 2.0/1.1
LAN	2.5GbE
Audio	Realtek ALC897
Wireless	No
Memory Speed	7600(O.C.)/7400(O.C.)/7200(O.C.)/7000(O.C.)/6800(O.C.)/6600(O.C.)/6400(O.C.)/6200(O.C.)/6000(O.C.)/5800(O.C.)/5600(O.C.)/5400/5200/4800 MHz
